Maschine zur Herstellung von Windeln

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers

Alle Kategorien

Maschine zur Herstellung von Windeln

Damenbinde, die Maschine herstellt

Underpad, das Maschine herstellt

Verpackungsmaschine für Windeln

Maschine zur Herstellung von Windeln

Unterwäsche-Liner-Maschine

Treten Sie mit uns in Verbindung

Mrs. Jessie

jessie@wm-machinery.com

18859442931

Kontaktieren Sie uns jetzt

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers

Markenbezeichnung:	Womeng
Modellnummer:	WM-SCK01
MOQ:	1 Stück
Preis:	$500,000.00-$800,000.00
Verpackungsdetails:	Seaworthy Holzkiste
Zahlungsbedingungen:	L/c, d/a, d/p, t/t

Einzelheiten

Produktbeschreibung

Einzelheiten

Herkunftsort:

Fujian, China

Zertifizierung:

Maschinenfarbe:

Nach Anpassung

Material:

Nicht gewebter Stoff, Saft, Flusenzellstoff

Stromspannung:

Steuerungssystem:

SPS -Kontrolle

Stapelungssystem:

Automatisches Stapelsystem

Produktgröße:

S, M, L, XL

Hauptmotor:

Servomotor

Produktionstyp:

Vollautomatisch

Gewicht:

100 Tonnen

Luftkompressor:

0,6-0,8mpa

Betriebsoberfläche:

Touch-Screen

Entwurfsgeschwindigkeit:

250-400pcs/min

Spannungsregelung der Beinmanschette:

Automatisch

Versorgungsmaterial-Fähigkeit:

12 Sätze/Jahr

Hervorheben:

full servo adult diaper machine

versatile diaper making machine

adult diaper machine various sizes

Produktbeschreibung

Product Info

Product size	M: 680X450 L: 800X650 XL: 950X760(Customixed according to customer requirement)
Product structure	Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker.
Control system	PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor
Drive system	Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings.
Tension system	Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B shaft active unwinding by inverter motor.
Safety system	It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer.
Packaging system	according to customer requirements with palletizer machine (double push double exit ) adjustable
Materials corrective system	Materials corrective system: Adopt international famous brand deviation correction system
Power	380V, 50HZ three phase five wire
Machine Capacity	400KW (Excluding glue machine and air compressor)
Bleed pressure	0.6-0.8Mpa (Air compressor needs to be prepared by customers)

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 0

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 1

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 2

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 3

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 4

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 6

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 7

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 8

Versatile Full Servo Adult Diaper Making Machine for Various Sizes and Styles of Diapers 11

Whatsapp: +008615805080212

Email:jessie@wm-machinery.com

https://www.diapersmachines.com

Adapt to diverse markets: It can meet the needs of different groups of people and scenarios

Multi-category quick switching: Supports full-category switching from "lightweight daily-use style", "thickened night-use style" to "leak-proof care style" and "adult pull-up pants". It only takes 40-80 minutes to change molds or adjust parameters (depending on the actual time), without the need for large-scale equipment modification. Customers can flexibly respond to the consumption preferences of the local market.

Adapt to different body types and demands: It can produce full-size products ranging from "M size (medium body type)" to "XXL size (obese body type)", and can also adjust the "leak-proof edge height" and "absorbent core thickness" according to regional needs (for example, adding thin breathability for tropical countries and enhancing warmth insulation for high-latitude regions), to meet the usage scenarios of local users.

Compatible with local raw materials: It can be adapted to non-woven fabrics, water-absorbing resins, elastic waist belts and other raw materials purchased locally by customers, without relying on specific imported materials. This not only reduces the transportation cost of raw materials but also avoids the impact on production due to supply chain disruptions (such as tariffs and logistics delays), making it particularly suitable for emerging markets with limited raw material procurement channels.
